RAADIOSAATJA BAOFENG UV-5R 5W
40€
Kuulutuse sisu Lisa lemmikutesse Jaga Facebookis
RAADIOSAATJA BAOFENG UV-5r 5w kõrvaklapiga / suure 3800mah akuga
Võimalik lisada jahisagedused (Jaht1, Jaht2, Jaht3)
Specifications:
Dual band, dual display
A/B band independent operation
128 groups channels storage
Shortcut menu operation mode
VFO & Memory channels scan
Emergency Alarm
Tri-color background light selectable
0~9 grades VOX selectable
PTT & ANI ID
FM radio and 25 stations storage
1750Hz Brust Tone
Time-out Timer
Channel Monitor
Battery Saver
Keypad Lock
Channel Step: 2.5/5/6.25/10/12.5/25KHz
Low Battery Alert
ROGER SET
Emergency Alert
25KHz/12.5KHz Switchable
FM Radio (65.0MHz-108.0MHz)
Large LCD Display
LED Flashlight
Hight /Low RF Power Switchable
Voice companding
50 CTCSS/ 104DCS coder & tone searching
dual standby
PC programmable
Wide/Narrow Band(25kHz/12.5kHz)
Transmitter time-out timer(TOT)
High/Low TX power selectable
Busy channel lock-out(BCLO)
Specifications
General
Frequency Range
65-108MHz(FM Receive only)
136-174MHZ and 400-520MHZ (TX/RX)
Channel No.
128
Frequency Stability
±2.5ppm
Antenna
High gain DualBand antenna
Antenna Impedance
50Ω
Operating Voltage
DC 7.4V
Mode of operation
Simple or semi-duplex
Dimension(W x H x D)
100 x 52 x 32 mm
Weight
250g(including battery, antenna)
Antenna :
SMA -Female
Earpiece / mic type :
Kenwood Plug type
Transmitter
Output power
8W/5W / 1W (Max 8W)
Modulation Mode
16kΦF3E / 11kΦF3E
Maximum deviation
5kHz(Wide) / 2.5kHz(Narrow)
Spurious Radiation
7μW
Adjacent Ch. power
≤-65dB(Wide) / ≤-60dB(Narrow)
Pre-emphasis characteristics
6dB
Current
≤1.6A(5W)
CTCSS/DCS deviation
0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow)
Intermediation sensitivity
8-12mv
Intermediation distortion
≤10%
Package Contain:
1× UV-5R 5W (VHF136-174 & UHF 400-520Mhz)
1× 7.4V 1800mah Li-ion Battery Pack
1× Dual Band Antenna
1× Belt Clip
1× ENG Manual
1× Desktop Charger ( 100V ~ 240V ) with Correct Adapter for your Country
1× Earpiece
1× Handstrap
